A Comprehensive Technical Whitepaper

Version 2.0 — April 2026 SINT AI Lab / PSHKV Inc. — Los Angeles, CA Authors: Illia Pashkov & SINT Agent Network

Abstract

SINT is an integrated AI operations ecosystem comprising a runtime authorization protocol for physical AI systems, a full-stack agent orchestration platform, an autonomous content engine, a 3D avatar interface, an outreach automation framework, and a public agent trust registry. The ecosystem is designed to enable AI agents to safely operate in the physical world — controlling robots, drones, surgical instruments, and industrial machinery — while maintaining human oversight, cryptographic accountability, and economic sustainability. The flagship component, SINT Protocol, inserts a single enforcement point — the Policy Gateway — between every AI agent and its physical or digital actions. Every request flows through graduated approval tiers (T0–T3), capability token validation, physical safety constraint checking, forbidden action sequence detection, and SHA-256 hash-chained audit logging. The reference implementation spans 24 packages, 5 applications, 3 SDKs (TypeScript, Python, Go), and 1,363 tests covering conformance against OWASP Agentic Security Top 10, IEC 62443, EU AI Act Article 13, and NIST AI RMF. The broader ecosystem includes:

SINT Operators Platform — React 19 orchestration dashboard with 30+ Redux slices, visual workflow canvas, Web3 bridge, and 1,276+ tests
Virtual CMO — AI content engine (331 files, 18 skills) that turns one video into a week of multi-platform content at ~$1.50/video
SINT Avatars — 3D talking avatar system with ARKit 52 blendshapes and ElevenLabs character-level lipsync
SINT Outreach — B2B LinkedIn automation with Ulinc/GHL integration and AI reply generation
Open Agent Trust Registry — Public federated registry of trusted attestation issuers with Ed25519 threshold governance
Autonomous Execution Engine — Marketing site with VRM avatar integration and Supabase backend

This whitepaper presents the complete technical architecture, implementation details, and research agenda for every component.

The Problem
Design Principles
SINT Protocol Architecture
Core Primitives
Approval Tier System
Capability Token Framework
Forbidden Combination Detection
Evidence Ledger
Bridge Adapters
Economic Layer
Safety Plugins
CSML Behavioral Identity
SINT Operators Platform
Virtual CMO Content Engine
3D Avatar System
Outreach Automation
Open Agent Trust Registry
Physical AI Use Cases
Conformance & Testing
Compliance & Standards Mapping
Competitive Landscape
Research Agenda (2026–2031)
Deployment & Operations
Roadmap
References

1. The Problem

1.1 The Physical AI Gap

AI systems are transitioning from passive text generators to active controllers of physical systems. In 2024–2025, LLMs became robotic co-pilots. By 2026–2027, they are becoming primary controllers. The security model for this world does not yet exist. Empirical evidence of the gap:

ROSClaw Study (arXiv:2603.26997): Evaluated frontier LLMs controlling ROS 2 robots. Found 4.8× behavioral divergence between models on identical tasks — the same robot performs radically differently depending on which foundation model drives it.
MCP Security Analysis (arXiv:2601.17549): Identified 10 critical attack surfaces in the Model Context Protocol, including tool poisoning, rug pulls, and cross-server escalation. MCP has no built-in authorization framework.
Unitree BLE Vulnerability: Consumer humanoid robots shipped with default BLE keys, enabling remote takeover. No runtime authorization layer between AI commands and physical actuators.

1.2 The Authorization Gap

Current AI safety research focuses on alignment — making models want the right things. But even a perfectly aligned model operating through tool-use interfaces (MCP, function calling, ROS 2 actions) has no standardized mechanism to enforce:

Who is authorized to perform an action
What physical constraints apply (velocity limits, force ceilings, geofences)
When human approval is required versus when autonomous operation is safe
How to produce a tamper-evident audit trail of every decision

Physical AI failures are not reversible with Ctrl+Z. A robot arm that exceeds force limits, a financial agent that transfers funds without authorization, or a code execution agent that runs destructive commands all produce real-world consequences.

1.3 Why Existing Protocols Don’t Solve This

Protocol	Focus	Physical Constraints	Graduated Auth	Audit Trail	Sequence Detection
MCP (Anthropic)	LLM ↔ Tool context	❌	❌	❌	❌
ACP (IBM/LF)	Agent-to-agent comms	❌	Partial	❌	❌
A2A (Google)	Agent interoperability	❌	❌	❌	❌
AgentProtocol	Framework-agnostic API	❌	❌	❌	❌
ANP	Agent networking	❌	❌	❌	❌
AG-UI	Agent UX streaming	❌	❌	❌	❌
SINT	Physical AI security	✅	✅	✅	✅

SINT is not a competing agent protocol. It is a security enforcement layer that sits between any agent protocol and the physical world.

2. Design Principles

Universal Interception — One choke point for all agent-to-world actions, regardless of transport protocol.
Graduated Authorization — Four approval tiers (T0–T3) map action severity to authorization requirements.
Physical Safety as First-Class — Velocity, force, and geofence constraints enforced at the protocol level.
Cryptographic Accountability — Ed25519 capability tokens and SHA-256 hash-chained audit logs provide non-repudiable proof of every authorization decision.
Attenuation-Only Delegation — Delegated permissions can only narrow, never escalate.
Emergency Stop Invariant — E-stop signals are NEVER blocked by the gateway (Invariant I-G2).
Consequence-Based Classification — Tier assignment based on real-world consequence severity, not syntactic properties.
Protocol Agnosticism — Works with any transport through pluggable bridge adapters.

3. SINT Protocol Architecture

3.1 System Overview

┌─────────────────────────────────────────────────────────────────────┐
│                  AI Agent (LLM / Controller / Swarm)                │
└──────────────────────────┬──────────────────────────────────────────┘
                           │ Raw request (tool call, topic publish, etc.)
┌──────────────────────────▼──────────────────────────────────────────┐
│                       Bridge Adapter Layer                          │
│  ┌──────────┐ ┌──────────┐ ┌──────────┐ ┌────────┐ ┌───────────┐  │
│  │ bridge-  │ │ bridge-  │ │ bridge-  │ │bridge- │ │ bridge-   │  │
│  │   mcp    │ │  ros2    │ │ mavlink  │ │  a2a   │ │   grpc    │  │
│  └──────────┘ └──────────┘ └──────────┘ └────────┘ └───────────┘  │
│  ┌──────────┐ ┌──────────┐ ┌──────────┐ ┌────────┐ ┌───────────┐  │
│  │ bridge-  │ │ bridge-  │ │ bridge-  │ │bridge- │ │ bridge-   │  │
│  │   iot    │ │  mqtt    │ │  opcua   │ │ swarm  │ │  open-rmf │  │
│  └──────────┘ └──────────┘ └──────────┘ └────────┘ └───────────┘  │
└──────────────────────────┬──────────────────────────────────────────┘
                           │ Normalized SintRequest
┌──────────────────────────▼──────────────────────────────────────────┐
│                      Policy Gateway (THE choke point)               │
│                                                                     │
│  ┌─────────────────────────────────────────────────────────────┐   │
│  │  1. Token Validation (Ed25519 signature + delegation chain) │   │
│  │  2. Tier Assignment (T0–T3 based on resource + context)     │   │
│  │  3. Physical Constraint Check (velocity, force, geofence)   │   │
│  │  4. Forbidden Combo Detection (sequence analysis, DFA)      │   │
│  │  5. Safety Plugins (GoalHijack, MemoryIntegrity, Supply)    │   │
│  │  6. CSML Auto-Escalation (behavioral drift detection)       │   │
│  │  7. CircuitBreaker (EU AI Act Art. 14(4)(e) stop button)    │   │
│  │  8. Rate Limiting (per-token, per-agent)                    │   │
│  │  9. Budget Enforcement (economic layer)                     │   │
│  │  10. Approval Flow (T2: review, T3: human-in-the-loop)     │   │
│  └─────────────────────────────────────────────────────────────┘   │
│                           │                                         │
│  ┌────────────────────────▼────────────────────────────────────┐   │
│  │         Evidence Ledger (SHA-256 hash-chained)              │   │
│  │  In-Memory │ PostgreSQL │ Redis │ (pluggable backends)      │   │
│  └─────────────────────────────────────────────────────────────┘   │
└──────────────────────────┬──────────────────────────────────────────┘
                           │ PolicyDecision: allow | deny | escalate
                           ▼
              ┌────────────────────────────┐
              │   Operator Dashboard       │
              │   + WebSocket approvals    │
              │   + M-of-N quorum          │
              │   + CSML trend charts      │
              └────────────────────────────┘

3.2 Request Lifecycle (Deterministic Finite Automaton)

Every request follows a deterministic state machine:

RECEIVED → VALIDATING → TIER_ASSIGNED → CONSTRAINT_CHECK
    │           │              │                │
    │        DENIED         DENIED           DENIED
    │      (bad token)    (blocked tier)   (constraint violation)
    │
    └→ COMBO_CHECK → CSML_CHECK → PLUGIN_CHECK → BUDGET_CHECK
           │              │              │              │
        ESCALATED      ESCALATED      DENIED        DENIED
       (forbidden     (drift         (hijack/       (insufficient
        sequence)     detected)      tamper)         balance)
           │              │
           ▼              ▼
    PENDING_APPROVAL → APPROVED/DENIED → LEDGER_RECORDED → COMPLETE
                          │
                       TIMEOUT → fallbackAction (deny|allow)

3.3 Monorepo Structure

The sint-protocol repository is a pnpm/Turborepo monorepo with 24 packages and 5 applications: Core Packages (8 publishable under @sint/ scope):

Package	Purpose	Lines (approx.)
`@sint/core`	Types, Zod schemas, DFA engine, tier constants	~800
`@sint/gate-capability-tokens`	Ed25519 tokens, delegation chains, revocation	~1,200
`@sint/gate-policy-gateway`	Single enforcement choke point, tier assignment, plugin system	~1,500
`@sint/gate-evidence-ledger`	SHA-256 hash-chained audit log, proof receipts	~900
`@sint/persistence`	Storage interfaces + in-memory/Redis adapters	~400
`@sint/persistence-postgres`	PostgreSQL adapter with migrations	~520
`@sint/bridge-mcp`	MCP tool call interception proxy	~600
`@sint/bridge-economy`	Metered billing, trust-tier pricing, route selection	~700
`@sint/client`	TypeScript SDK for Gateway HTTP API	~300

Bridge Adapter Packages (9):

Package	Protocol	Key Feature
`bridge-ros2`	ROS 2 topics, services, actions	Auto-extracts velocity/force from geometry_msgs
`bridge-mavlink`	MAVLink v2 (PX4/ArduPilot)	ARM/DISARM, TAKEOFF, MISSION_START mapping
`bridge-a2a`	Google Agent-to-Agent	Cross-org agent delegation
`bridge-iot`	Generic IoT	Sensor/actuator classification
`bridge-mqtt`	MQTT pub/sub	Topic → resource URI mapping
`bridge-opcua`	OPC-UA (IEC 62541)	Legacy PLC integration
`bridge-grpc`	gRPC services	Service mesh interception
`bridge-swarm`	Multi-agent coordination	Collective constraint enforcement
`bridge-open-rmf`	Open-RMF fleet management	Robot fleet resource mapping

Intelligence Engines (4):

Package	Function
`engine-system1`	Fast perception: sensor fusion, anomaly detection
`engine-system2`	Deliberative planning: path planning, task scheduling
`engine-hal`	Hardware abstraction layer
`engine-capsule-sandbox`	Sandboxed code execution environment

Applications (5):

App	Stack	Description
`gateway-server`	Hono HTTP	REST API + WebSocket approvals + SSE streaming
`dashboard`	React	Real-time approval UI + conformance dashboard
`sintctl`	CLI	Token management, approvals, ledger queries, policy management
`sint-mcp`	Node.js	MCP proxy bridge (drop-in for Claude Desktop, Cursor)
`sint-mcp-scanner`	Node.js	MCP server security scanner

SDKs (3):

SDK	Language	Lines	Features
`sint-python`	Python 3.10+	1,962	Client, scanner, token management, Pydantic models
`sint-go`	Go 1.21+	~200	Client stub
`@sint/client`	TypeScript	~300	Full Gateway HTTP API client

4. Core Primitives

4.1 SintRequest

Every agent action is normalized to this structure before gateway evaluation:

interface SintRequest {
  requestId: UUIDv7;                    // Unique, sortable identifier
  agentId: Ed25519PublicKey;            // 32-byte hex public key
  tokenId: UUIDv7;                      // Capability token authorizing this request
  resource: string;                     // URI: "ros2:///cmd_vel", "mcp://filesystem/writeFile"
  action: string;                       // "publish", "call", "subscribe", "exec.run"
  params: Record<string, unknown>;      // Action-specific parameters
  physicalContext?: {
    humanDetected?: boolean;            // Triggers tier escalation
    currentVelocityMps?: number;
    currentForceNewtons?: number;
    position?: { lat: number; lon: number };
  };
  recentActions?: string[];             // Last N actions for combo detection
  timestamp: ISO8601;                   // Microsecond precision
}

4.2 PolicyDecision

The gateway’s response to every request:

interface PolicyDecision {
  action: "allow" | "deny" | "escalate" | "transform";
  requestId: UUIDv7;
  assignedTier: "T0_OBSERVE" | "T1_PREPARE" | "T2_ACT" | "T3_COMMIT";
  assignedRisk: "T0_READ" | "T1_WRITE_LOW" | "T2_STATEFUL" | "T3_IRREVERSIBLE";
  denial?: {
    reason: string;
    policyViolated: string;
    suggestedAlternative?: string;
  };
  escalation?: {
    requiredTier: ApprovalTier;
    reason: string;
    timeoutMs: number;                  // Max 300,000ms (5 min)
    fallbackAction: "deny" | "allow";
  };
  transformations?: {
    constraintOverrides?: Record<string, unknown>;
    additionalAuditFields?: Record<string, unknown>;
  };
  timestamp: ISO8601;
}

4.3 Resource URI Scheme

All resources are identified by URIs with protocol-specific schemes:

Scheme	Format	Example
`ros2://`	`ros2:///<topic_or_service>`	`ros2:///cmd_vel`
`mcp://`	`mcp://<server>/<tool>`	`mcp://filesystem/writeFile`
`mavlink://`	`mavlink://<systemId>/<command>`	`mavlink://1/arm`
`a2a://`	`a2a://<host>/<task>`	`a2a://wms.example.com/deliver`
`grpc://`	`grpc://<service>/<method>`	`grpc://robot.v1/Move`
`mqtt://`	`mqtt://<broker>/<topic>`	`mqtt://factory/robot/01/cmd_vel`
`opcua://`	`opcua://<server>/<nodeId>`	`opcua://plc1/ns=2;s=MotorSpeed`
`http://`	Standard HTTP	`http://api.example.com/v1/transfer`

Glob patterns are supported: mcp://*, ros2:///sensor/*.

5. Approval Tier System

5.1 Tier Definitions

Tier	Enum	Auto-Approved	Requires	Physical Example	Digital Example
T0	`T0_OBSERVE`	Yes (logged)	—	Read sensor data	Query database
T1	`T1_PREPARE`	Yes (audited)	—	Save waypoint, plan path	Write file, stage config
T2	`T2_ACT`	No	Review	Move robot, operate gripper	Modify database, deploy
T3	`T3_COMMIT`	No	Human	Emergency stop override, mode change	Execute code, transfer funds

Shell and code-execution tool names (bash, exec, eval, run_command, etc.) are explicitly classified at T3_COMMIT to address OWASP ASI05.

5.2 Tier Escalation Triggers

Base tier is escalated (never de-escalated) by contextual signals:

Trigger	Effect	Rationale
Human detected near robot	T2 → T3	ISO 10218-1 §5.4 presence detection
New/untrusted agent	+1 tier	Unknown agents get tighter scrutiny
Forbidden combo detected	→ T3	Dangerous sequences require human approval
CSML threshold exceeded	+1 tier	Behavioral drift detected
Server `requireApproval: true`	Non-T0 → escalate	Operator-configured per-server policy
Velocity/force exceeds constraint	→ deny	Hard physical safety limit
CircuitBreaker tripped	→ deny all	Emergency kill switch (EU AI Act Art. 14(4)(e))
GoalHijackPlugin alert	→ deny	Prompt injection / role override detected

5.3 Approval Flow

Request (T2/T3) → Pending Approval → Notification (SSE/WebSocket/Dashboard)
    → Operator approves/denies → PolicyDecision → Ledger Entry
    → Timeout (default 30s, max 5min) → fallbackAction: deny

M-of-N quorum approval is supported for T3 actions requiring multiple operator sign-off.

6. Capability Token Framework

6.1 Token Structure

interface CapabilityToken {
  id: UUIDv7;
  issuer: Ed25519PublicKey;
  subject: Ed25519PublicKey;
  resource: string;                     // Glob-supported
  actions: string[];
  constraints: {
    maxVelocityMps?: number;
    maxForceNewtons?: number;
    geofence?: GeoPolygon;
    timeWindow?: { start: ISO8601; end: ISO8601 };
    rateLimit?: { maxCalls: number; windowMs: number };
  };
  delegationChain: {
    parentTokenId: UUIDv7 | null;
    depth: number;                      // 0 = root, max 3
    attenuated: boolean;
  };
  issuedAt: ISO8601;
  expiresAt: ISO8601;
  revocable: boolean;
  signature: Ed25519Signature;          // 64-byte
}

6.2 Delegation Rules

Maximum depth: 3. Root (0) → 1 → 2 → 3. No further delegation.
Attenuation only. Each delegation MUST have equal or narrower scope, fewer actions, tighter constraints, earlier expiry.
Chain verification. Validators verify the entire chain — each hop’s signature and attenuation.
Revocation cascades. Revoking a parent implicitly revokes all descendants.

6.3 Cryptographic Primitives

Signing: Ed25519 via @noble/ed25519 (audited, zero-dependency)
Hashing: SHA-256 via @noble/hashes
Identity: W3C DID (did:key:z6Mk...) for cross-organizational trust

7. Forbidden Combination Detection

The gateway maintains rules for action sequences that are individually permitted but dangerous in combination.

7.1 Default Forbidden Combos

Sequence	Risk	Escalation
`filesystem.write` → `exec.run`	Code injection	→ T3
`credential.read` → `http.request`	Credential exfiltration	→ T3
`database.write` → `database.execute`	SQL injection escalation	→ T3
`ARM` → `SET_MODE(OFFBOARD)` (within 2s)	Full autonomous takeover	→ T3
`FENCE_DISABLE` → navigation (within 30s)	Geofence bypass	→ T3
`safety.cell_unlock` → `torch.enable` (within 100ms)	Human safety risk	→ T3

7.2 Detection Algorithm

Each request includes recentActions[] — last N actions (configurable, default 10).
Detector checks if current action completes any registered forbidden sequence.
Match found → tier escalated to T3, reason recorded in ledger.
Operators extend the default list with domain-specific forbidden combinations.

8. Evidence Ledger

8.1 Ledger Entry

interface LedgerEvent {
  id: UUIDv7;
  sequenceNumber: number;              // Monotonically increasing
  previousHash: SHA256Hash;            // Genesis = "0".repeat(64)
  eventHash: SHA256Hash;               // SHA-256(previousHash + serialized data)
  eventType: "intercept" | "token_issued" | "token_revoked" | "approval_resolved";
  agentId: Ed25519PublicKey;
  requestId?: UUIDv7;
  decision?: PolicyDecision;
  metadata: Record<string, unknown>;
  timestamp: ISO8601;
}

8.2 Integrity Properties

Hash chain: Each entry’s hash includes the previous hash. Any modification breaks all subsequent entries.
Proof receipts: Cryptographic proof sufficient to verify any entry independently.
Append-only: Entries are never updated or deleted.
TEE attestation: Planned support for Intel SGX, ARM TrustZone, AMD SEV for hardware-backed proof receipts.

8.3 Storage Backends

Backend	Use Case	Implementation
In-memory	Testing, development	✅ Shipped
PostgreSQL	Production single-node	✅ Shipped (518 lines, full migrations, pool management, rate-limit + revocation stores)
Redis	High-throughput, pub/sub revocation bus	✅ Shipped (cache + revocation bus)

8.4 API

# Query by agent
GET /v1/ledger?agentId=<key>&limit=100

# Query by tier
GET /v1/ledger?tier=T3_COMMIT&since=2026-04-01

# Export for SIEM integration (Splunk, Datadog, ELK)
GET /v1/ledger?format=json-lines&since=2026-04-01

9. Bridge Adapters

9.1 MCP Bridge (Primary Adoption Vector)

SINT’s MCP proxy sits between AI clients (Claude, Cursor, GPT) and downstream MCP servers:

{
  "mcpServers": {
    "sint-proxy": {
      "command": "npx",
      "args": ["@sint/bridge-mcp", "--downstream", "filesystem,exec"]
    }
  }
}

The proxy intercepts every tool call, evaluates it against the policy gateway, and exposes introspection tools:

sint__status — Current token scope and tier configuration
sint__audit — Recent ledger entries for this session
sint__approve — Trigger approval flow for pending requests

Integration guides available for:

Claude Desktop — Drop-in MCP proxy configuration (11,472 lines of documentation)
Cursor IDE — MCP proxy with SINT integration
Docker — Production deployment with PostgreSQL + Redis
gRPC — Service mesh bridge setup
WebSocket — Real-time approval streaming

9.2 ROS 2 Bridge

Intercepts ROS 2 topic publishes, service calls, and action goals:

Resource mapping: ros2:///<topicOrServiceName>
Physics extraction: Automatically extracts velocity from geometry_msgs/Twist and force from geometry_msgs/Wrench
Human presence: Subscribes to detection topics for automatic tier escalation

9.3 MAVLink Bridge

Translates MAVLink v2 commands (PX4, ArduPilot) to SINT requests:

MAVLink Command	SINT Tier	Rationale
ARM/DISARM	T3	Enables/disables propulsion
TAKEOFF/LAND	T2	Physical approach
MISSION_START	T3	Begins autonomous BVLOS
FENCE_DISABLE	T3	Removes safety boundary
SET_MODE(OFFBOARD)	T3	Full autonomous control

9.4 Additional Bridges

Bridge	Protocol	Standard	Key Feature
`bridge-a2a`	Google A2A	—	Cross-org agent delegation with token forwarding
`bridge-grpc`	gRPC (176 lines)	—	Service mesh interception, proto reflection
`bridge-iot`	Generic IoT	—	Sensor/actuator auto-classification
`bridge-mqtt`	MQTT pub/sub	—	Topic → resource URI, wildcard matching
`bridge-opcua`	OPC-UA	IEC 62541	Legacy PLC integration, NodeId mapping
`bridge-swarm`	Multi-agent	NATO STANAG 4586	Collective constraint enforcement
`bridge-open-rmf`	Open-RMF	—	Robot fleet management, task allocation

10. Economic Layer

10.1 Token Unit

SINT uses an integer token unit — no fractional amounts:

Constant	Value	Source
`TOKENS_PER_DOLLAR`	250	`pricing-calculator.ts`
`INITIAL_USER_BALANCE`	250 tokens ($1.00)	Default for new users
Launch pricing	1 token ≈ $0.001	`1 / TOKENS_PER_DOLLAR`

New users start with 250 tokens (~27 default MCP tool calls).

10.2 Billing Formula

cost = ceil(baseCost × costMultiplier × globalMarkupMultiplier)

Parameter	Default	Notes
`baseCost`	6 tokens	Standard MCP/tool call
`costMultiplier`	1.0	Per-resource or marketplace rate
`globalMarkupMultiplier`	1.5	`GLOBAL_MARKUP_MULTIPLIER` constant
Default result	9 tokens	`ceil(6 × 1.0 × 1.5)`

10.3 Tier-Based Cost Table

Tier	Action Type	Base Cost	Typical Result
T0 — Observe	Read/query (sensor, subscribe)	4–6	~6–9
T1 — Prepare	Low-impact write (save waypoint)	6	9
T2 — Act	Physical state change (ROS 2 publish)	8	12
T3 — Commit	Capsule execution, irreversible action	12	18

Physical-domain bridges carry higher multipliers:

Bridge / Resource Prefix	Typical `costMultiplier`
MCP tool call (default)	1.0
ROS 2 publish (`ros2://`)	1.0–2.0
MAVLink command (`mavlink://`)	2.0–5.0
Capsule execution (`capsule://`)	1.0–3.0

10.4 Budget Enforcement

Budget enforcement runs in EconomyPlugin.preIntercept(), called before PolicyGateway assigns tiers:

checkBudget() — per-agent budget cap
getBalance() — sufficient balance check
evaluateTrust() — not blocked/high-risk

Post-intercept (on allow): withdraw(userId, tokens). Balance shortfall → deny (never escalate).

10.5 Revenue Split (Design)

Recipient	Share
Operator (MCP server / bridge host)	70%
Protocol treasury	20%
Safety reserve fund	10%

10.6 Cost-Aware Route Selection

@sint/bridge-economy includes route scoring for multi-bridge execution:

selectCostAwareRoute(input) — scores by cost + latency + reliability
POST /v1/economy/route — exposed through gateway API

11. Safety Plugins

The Policy Gateway supports a plugin architecture for extensible safety checks. These run after tier assignment but before approval flow.

11.1 GoalHijackPlugin (OWASP ASI01)

5-layer heuristic detection of prompt injection:

Role override detection — Pattern matching for “ignore previous instructions”, system prompt injection
Semantic escalation — Requests that attempt to expand scope beyond token permissions
Exfiltration probes — Attempts to read credentials, env vars, or PII
Cross-agent injection — Messages crafted to manipulate downstream agents
Prompt injection in tool parameters — Embedded instructions in tool call arguments

11.2 MemoryIntegrityChecker (OWASP ASI06)

Detects manipulation of agent memory/context:

Replay attack detection (duplicate request IDs)
Privilege claim detection (forged approval records)
History overflow anomalies (context window stuffing)

11.3 DefaultSupplyChainVerifier (OWASP ASI04)

Validates model and tool integrity:

Model fingerprint hash verification against allowlist
Model ID validation at runtime
Tool manifest integrity checking (detects swapped/tampered tools)

11.4 CircuitBreakerPlugin (EU AI Act Art. 14(4)(e))

Emergency stop mechanism:

Manual trip() by operator → instantly blocks all actions from target agent
N consecutive denials → auto-open circuit
CSML anomalous-persona detection → auto-trip
HALF_OPEN probe recovery → self-healing after incident resolution

11.5 DynamicEnvelopePlugin

Environment-adaptive constraint tightening:

effective_max_velocity = min(token.maxVelocityMps, obstacle_distance × reaction_factor)

Real-time sensor state (obstacle distance, human proximity) is mapped to tighter effective limits, closing the gap between static token constraints and dynamic environment conditions.

11.6 SwarmCoordinator

Collective constraints for multi-agent deployments:

Maximum concurrent actors in T2+ tier
Total kinetic energy ceiling (Σ½mv²)
Minimum inter-agent distance
Maximum escalated fraction

These cannot be captured by per-agent token scoping alone.

12. CSML Behavioral Identity

12.1 Definition

CSML (Composite Safety-Model Latency) is a behavioral fingerprint metric that detects when an agent’s behavior deviates from its established pattern. Computed per foundation_model_id:

interface CSMLMetrics {
  approvalRate: number;     // approved / total requests
  completionRate: number;   // completed / started actions
  averageLatencyMs: number; // mean decision time
  tierDistribution: Record<ApprovalTier, number>;
}

// CSML score = weighted divergence from baseline
function computeCsml(current: CSMLMetrics, baseline: CSMLMetrics): number;

12.2 Auto-Escalation

When CSML exceeds a configurable threshold (θ), the agent’s tier is automatically escalated. Thresholds vary by deployment context:

Context	Default θ	Human-Present θ
Warehouse AMR	0.30	0.15
Welding arm (ISO 10218)	0.30	0.10
Surgical robot (FDA Class III)	0.10	0.10
Drone BVLOS	0.35	0.20
Collaborative robot (ISO/TS 15066)	0.15	0.15

12.3 ROSClaw Validation

The ROSClaw study (arXiv:2603.26997) empirically confirmed CSML’s premise: frontier LLMs exhibit up to 4.8× differences in out-of-policy action proposal rates on identical tasks. CSML makes this variance enforcement-visible rather than a post-incident finding.

13. SINT Operators Platform

Repository: github.com/sint-ai/sint-agents The SINT Operators Platform is a full-stack React 19 web application for AI agent orchestration and management. It serves as the control plane for the entire SINT ecosystem.

13.1 Technical Stack

Layer	Technology
Framework	React 19, TypeScript 5.6, Vite 6.1
State	Redux Toolkit 2.5 (30+ slices), Jotai
Routing	React Router DOM 7.1 (lazy-loaded pages)
Styling	styled-components 6.1
Flow Editor	@xyflow/react (React Flow)
Charts	Recharts, lightweight-charts
3D	Three.js, @react-three/fiber
Web3	wagmi, viem, ethers, @solana/web3.js, @cosmjs
Auth	Keycloak (OIDC via react-oidc-context)
Validation	Zod schemas for all gateway events
Real-time	WebSocket (JSON-RPC 2.0) with Ed25519 device identity
Backend	Express + SQLite (Conductor API)
Testing	Vitest — 1,276+ tests across 102+ test files

13.2 Feature Modules (28 modules)

Module	Description
Conductor	Multi-agent orchestration with risk-tiered approval workflows (T0-T3), policy enforcement, MCP 2.0 evidence chains. API layer, components, hooks, store with reducers, type definitions, and utility functions
Canvas	Visual node-based workflow editor (React Flow) with topological execution engine, template gallery, flow toolbar, node config panels, n8n integration
Agents	Agent deployment and management from templates — hierarchy view, detail panel, deploy dialog, heartbeat monitor, soul config editor, Paperclip API integration
Approval	Risk-tiered approval gates — enhanced approval cards, notification system
Audit	Audit log viewer with evidence chain visualization
Billing	Balance overview, spending charts, transaction lists, usage breakdowns, CSV export
Budget	Per-agent and session budget tracking and enforcement
Trust	Trust policy engine for agent reputation management
Anomaly	Anomaly detection dashboard for behavioral outliers
Intelligence	Intelligence platform with API integration and dedicated hooks
Memory	Agent memory inspection and shared context management
Sessions	Session lifecycle management
Tasks	Kanban-style task management with Paperclip API integration
Traces	Distributed trace viewing for debugging agent flows
Schedules	Cron-style scheduling management
Webhooks	Webhook management for external integrations
Trading	Live price feeds (CoinGecko), watchlists, portfolio tracking, backtesting
Web3	Multi-chain wallet bridge (Ethereum, Solana, Cosmos, ZetaChain)
Marketplace	Agent and skill marketplace
Templates	Agent template management and export
Metrics	Analytics dashboard
Handoffs	Inter-agent handoff protocol
Shared Context	Shared context template management
Run Events	Run event streaming
Notifications	Notification center
Cost	Cost tracking components
Settings	Platform configuration
Profile	User profile management
Command Bar	Quick command palette

13.3 Pages (26 routes)

Page	Function
Home	Landing/dashboard
Chat	Text and voice chat with AI agents (Deepgram STT/TTS)
Dashboard	Overview metrics
Canvas	Visual workflow editor
Intelligence	Intelligence platform
AgentManager	Agent deployment and monitoring
ConductorDashboard	Conductor overview
ConductorApprovals	Approval queue
ConductorEvidence	Evidence chain viewer
ConductorPolicy	Policy configuration
ConductorServers	Server management
MetricsDashboard	Analytics
ObservabilityPage	Observability tools
OperatorTasks	Task management
OperatorSessions	Session management
OperatorTraces	Trace viewing
OperatorMemory	Memory inspection
OperatorBilling	Billing dashboard
OperatorSettings	Settings
OperatorProfile	Profile
TradingDashboard	Trading terminal
Web3Dashboard	Web3 bridge
ZetaChain	ZetaChain integration
Marketplace	Marketplace
Leaderboard	User ranking
Billing	Billing management

13.4 WebSocket Gateway

Real-time communication layer:

GatewayClient.ts — WebSocket connection with auto-reconnect and auth
GatewayProvider.tsx — React context for event routing
15+ event handlers — Factory-pattern handler registration
gatewayIdentity.ts — Ed25519 keypair generation for device auth
Zod validators — Schema validation for all gateway events

14. Virtual CMO Content Engine

Repository: github.com/sint-ai/sint-cmo-operator The Virtual CMO is an AI content engine that transforms one video into a week of multi-platform content. It represents SINT’s approach to autonomous content operations.

14.1 Pipeline Architecture

Video Input → Download → Transcribe (AssemblyAI/Whisper)
    → Analyze (Claude 3-pass) → Face Track (MediaPipe)
    → Render (Remotion/FFmpeg) → Generate Text (Claude)
    → Quality Score → Approval Queue → Publish

14.2 Technical Stack

331 files total in repository
API server: Express.js with 40+ route modules
Core engine: Pipeline engine with YAML-driven workflow definitions
Rendering: Remotion for programmatic video (React-based compositions — BrandOverlay, CaptionRenderer, ClipComposition, FaceCrop)
Transcription: AssemblyAI + local Whisper fallback
LLM routing: Multi-provider router (Claude, OpenAI, etc.)
Auth: API key service + OAuth manager + auth middleware
Scheduling: CMO scheduler with cron-based automation

14.3 Skills (18 modular processors)

Skill	Function
`asset-ingester`	Ingest and normalize input media
`brand-researcher`	Research brand voice and guidelines
`competitor-analyzer`	Competitive content analysis
`content-analyzer`	Deep content analysis (3-pass Claude)
`content-publisher`	Multi-platform publishing orchestrator
`content-repurpose`	Repurpose content across formats (6 sub-modules: angle extractor, hashtag researcher, input analyzer, media generator, platform generator, quality scorer)
`image-generator`	AI image generation for social posts
`linkedin-writer`	LinkedIn-optimized post generation
`newsletter`	Newsletter content generation
`notifier`	Telegram + general notification delivery
`output-packager`	Package deliverables for export
`platform-formatter`	Platform-specific format adaptation
`schema-generator`	Content schema generation
`seo-blog`	SEO-optimized blog post generation
`seo-optimizer`	SEO optimization pass
`serp-scraper`	SERP data collection for SEO
`social-calendar`	7-day social media calendar generation
`video-clipper`	Intelligent clip extraction
`video-repurpose`	Full video repurpose pipeline (download → transcribe → face-track → analyze → render → generate text)

14.4 Publishing Integrations

Platform	Integration
YouTube Shorts	OAuth + upload API
TikTok	OAuth + upload API
Instagram	Graph API
LinkedIn	OAuth + share API
Twitter/X	OAuth + tweet API
Telegram	Bot API

14.5 Services

Service	Function
CMO Autonomy	Autonomous decision-making engine
CMO Guardrails	Content compliance checking
CMO Quality	Content quality scoring
CMO Strategy	Content strategy generation
CMO Trends	Trend detection and analysis
CMO Timing	Optimal posting time calculation
CMO Competitors	Competitor monitoring
Evidence Ledger	Analytics and audit trail
Feedback Loop	Performance → improvement cycle
Approval Engine	Human-in-the-loop content approval
Brand Voice Engine	Brand consistency enforcement
Brandbook Processor	Brand guidelines extraction

14.6 External Integrations

MCP Skill Server — Exposes CMO capabilities as MCP tools
OpenClaw Connector — Integration with OpenClaw agent platform
Telegram Bot — Direct Telegram channel management
WhatsApp Bot — WhatsApp Business integration
Zapier Routes — Webhook/Zapier automation

14.7 Cost Analysis

Platform	Cost per Video	Notes
Opus Clip	$15–30	Cloud-based
Repurpose.io	$15–25	Limited customization
SINT CMO	~$1.50	Self-hosted, full customization

15. 3D Avatar System

Repository: github.com/sint-ai/sint-avatars The avatar system provides a 3D talking character interface for human-agent interaction.

15.1 Architecture

User Input → Server (OpenAI LLM for text + emotion tags)
    → ElevenLabs TTS (MP3 + character-level alignment timestamps)
    → Viseme Conversion (alignment → ARKit blendshape targets)
    → Client (MP3 base64 + lipsync data)
    → Three.js Renderer (morph target animation synchronized to audio)

15.2 Client (apps/client)

Rendering Stack: Three.js + React Three Fiber + drei 3D Systems:

Avatar module — AvatarNew, AvatarOptimized, AvatarOriginal, AvatarScene, CharacterControls
Animation system — External animation loading, idle animation, alive system (subtle breathing/movement)
Lipsync — ElevenLabs character-level timestamps → viseme codes (A-X) → ARKit 52 blendshapes → morph target interpolation
Camera system — CameraFollow, CameraRig with configurable defaults
Effects — Post-processing pipeline
Scene management — Multiple scene configurations with lighting constants

Interaction Systems:

useVoiceRecorder — User voice input capture
useBargein — Interrupt detection (user speaks while avatar is talking)
useAvatarBehavior — Behavioral state machine
useAvatarAnticipation — Pre-load animations based on conversation context
useBlink — Realistic blink patterns
useGPUTier — Adaptive quality based on device capability
useMorphTargets — Blendshape target management

Debug: DebugHUD with live tuning of viseme mappings, expression weights, and animation parameters.

15.3 Server (apps/server)

Stack: Node.js/TypeScript

Character system — Configurable character personalities
Conversation compiler — Assembles conversation context
Conversation filter — Content moderation
Streaming chat — Streaming LLM responses with emotion tagging
OpenClaw backend — Integration with OpenClaw agent platform
Static audio assets — Pre-generated greetings, error messages for instant playback

15.4 Shared Package (packages/shared)

ARKit 52 blendshape definitions and mappings
Shared types between client and server
Utility functions

15.5 Expression System

12 expressions with configurable LERP speeds, 21 skeletal animations, multiple characters (girl, boy, SINT).

16. Outreach Automation

Repository: github.com/sint-ai/sint-outreach B2B LinkedIn outreach automation platform, deployed as “BrightBeam” for the first client.

16.1 Architecture

Backend: FastAPI (Python)

Module	Function
`agents/compliance.py`	FDA/FTC/LinkedIn ToS compliance checking
`agents/intent_detector.py`	Response intent classification
`agents/pipeline_mgr.py`	Pipeline stage management
`agents/prospector.py`	ICP-targeted prospect research
`agents/stage_classifier.py`	Conversation stage classification
`agents/triage.py`	Response triage and routing
`agents/writer.py`	AI reply generation
`state_machine.py`	Contact lifecycle state machine
`hitl/escalation.py`	Human-in-the-loop escalation
`hitl/feedback.py`	Feedback collection
`hitl/notifications.py`	Alert routing

Integrations:

Integration	Function
Ulinc	LinkedIn automation (invitation-only platform)
GoHighLevel (GHL)	CRM pipeline management
Email (SMTP)	Email channel support
LinkedIn MCP	MCP-based LinkedIn tool access
NPPES	Healthcare provider lookup
Outscraper	Business data enrichment
WhatsApp	WhatsApp Business messaging

Database: PostgreSQL with Alembic migrations (6 migration versions covering initial schema, campaign manager, contact lifecycle, conversation stage, A/B testing, email channel). Dashboard: React (Vite) with 5 pages:

Pipeline — Lead pipeline visualization
Campaigns — Campaign management
Analytics — Performance analytics
Escalations — HITL escalation queue
Agent Chat — Direct agent interaction

16.2 A/B Testing

Built-in experiment framework with:

Multiple message variants per sequence step
Statistical significance calculation
Winner evaluation and auto-promotion

16.3 Compliance

BrightBeam targets the supplements/peptides/longevity vertical (David Steel / BrightBeam):

FDA compliance for supplement claims
FTC endorsement guidelines
LinkedIn Terms of Service adherence
CAN-SPAM compliance for email channel

17. Open Agent Trust Registry

Repository: github.com/pshkv/open-agent-trust-registry A public, federated registry of trusted attestation issuers — the Certificate Authority trust store for the agent internet.

17.1 Problem Statement

When an AI agent presents an attestation (“I am authorized to act for this user”), the receiving service needs to verify the attestation issuer is legitimate. The registry is the master list of trustworthy badge issuers.

17.2 Architecture

Registry Structure:

registry/
├── issuers/                    # One JSON file per registered issuer
│   ├── agent-passport-system.json
│   ├── agentid.json
│   ├── agentinternetruntime.json
│   ├── agora.json
│   ├── arcede.json
│   ├── arkforge.json
│   ├── insumerapi.json
│   └── qntm.json
├── manifest.json               # Compiled, signed registry manifest
└── proofs/                     # Cryptographic proofs

CLI (@open-agent-trust/cli):

Command	Function
`keygen`	Generate Ed25519 keypair for issuer identity
`register`	Create registration file with domain proof
`submit`	Submit registration to registry
`verify`	Verify an attestation against registry
`issue`	Issue an attestation for an agent
`prove`	Generate cryptographic proof
`compile`	Compile registry manifest

17.3 Security Properties

Permissionless registration — Organizations register by cryptographically proving domain ownership. Automated CI pipeline adds them. No human gatekeepers.
Threshold governance — Master list secured by 3-of-5 multi-signature scheme. Keys distributed to independent ecosystem leaders.
Zero-trust mirrors — Registry manifest is cryptographically signed. Anyone can host a mirror; tampered manifests are rejected by SDK.
Local verification — Services download registry once and verify locally. No per-request central server calls.

17.4 CI/CD

manifest-compiler.yml — Compiles registry on changes
verify-registration.yml — Validates new registrations
release.yml — npm publish for CLI

17.5 Research Paper

“Composable Agent Trust Stack” — available at arcede.com/papers, documenting the broader vision and architecture.

18. Physical AI Use Cases

18.1 Warehouse Delivery Robot (AMR)

Standards: ISO 3691-4, IEC 62443

Action	SINT Tier	Constraint
LiDAR/camera subscribe	T0	—
Receive task via A2A	T1	—
Navigate (no humans)	T2	maxVelocity: 1.5 m/s
Navigate (humans detected)	T3	maxVelocity: 0.3 m/s
Gripper operation	T2	maxForce: 30 N
Emergency stop	NEVER BLOCKED	Invariant I-G2

18.2 Industrial Welding Arm (ISO 10218)

Action	SINT Tier	Constraint
Read joint angles	T0	—
Plan weld path	T1	—
Begin weld sequence	T2	maxForce: 500 N, cell_locked: true
Move arm (human in cell)	T3	maxVelocity: 0.1 m/s (ISO 10218-1 §5.4.3)
E-stop override	BLOCKED	I-G2 invariant

18.3 Surgical Robot (FDA Class III)

Standards: IEC 62304, IEC 60601-1-8, FDA 21 CFR Part 820, ISO 14971

Action	SINT Tier	Constraint
Instrument positioning	T2	maxVelocity: 0.01 m/s (sub-mm precision)
Force application	T2	maxForce: 5 N
Electrocautery	T3	surgeon_confirmed: true (irreversible tissue damage)
Emergency retract	NEVER BLOCKED	Safety retract always forwarded

18.4 UAV / Drone (MAVLink)

Standards: ASTM F3548-21, EU U-Space, FAA AC 107-2B

Action	SINT Tier	Constraint
ARM/DISARM	T3	Propulsion enable/disable
TAKEOFF	T2	altitude ≤ 120m (FAA Part 107)
MISSION_START	T3	Begins autonomous BVLOS
FENCE_DISABLE	T3	Removes safety boundary

18.5 Collaborative Robot (ISO/TS 15066)

Power-and-force limiting mode with continuous human presence:

maxVelocity: 0.25 m/s, maxForce: 150 N (ISO/TS 15066 Table 1 transient contact)
Per-body-region force limits: Head 130N, Chest 140N, Hand 140N, Thigh 220N

18.6 Underwater ROV (DNV-ST-0111)

Action	SINT Tier	Constraint
Thruster control	T2	maxVelocity: 1.0 m/s
Manipulator	T2	maxForce: 200 N
Emergency surface	ALWAYS FORWARDED	Never blocked

19. Conformance & Testing

19.1 Test Suite Summary

Component	Repository	Tests
SINT Protocol (full stack)	sint-protocol	1,363
Operators Platform	sint-agents	1,276+
Ecosystem total	all repos	2,639+

19.2 Protocol Test Coverage

Category	Tests	Coverage
Core types & Zod schemas	~80	Validation, DFA states
Capability tokens	~120	Issuance, delegation, revocation, chain verification
Policy gateway	~150	Tier assignment, constraint checking, escalation, plugins
Evidence ledger	~90	Hash chain integrity, proof receipts, queries
Bridge adapters	~200	MCP, ROS 2, MAVLink, A2A, gRPC, IoT, MQTT, OPC-UA
OWASP Conformance	~300	All 10 ASI categories
Economic layer	~70	Billing, budget, route selection
Avatar/CSML	~50	Behavioral drift detection
Persistence	~60	PostgreSQL, Redis, in-memory
CLI (sintctl)	~40	Token management, approvals
Edge mode conformance	~40	Offline operation
Economy fixtures	~20	Pricing calculator validation
Integration tests	~140	End-to-end gateway flows

19.3 OWASP Agentic Security Top 10 Coverage

#	OWASP Category	SINT Enforcement
ASI01	Goal Hijack / Prompt Injection	GoalHijackPlugin (5-layer detection)
ASI02	Tool Misuse	Tier-based approval gates + forbidden combo detection
ASI03	Identity Abuse	Ed25519 capability tokens + W3C DID
ASI04	Supply Chain Compromise	DefaultSupplyChainVerifier (model hash + tool manifest)
ASI05	Code Execution	T3_COMMIT classification for all exec tools
ASI06	Memory Poisoning	MemoryIntegrityChecker (replay, privilege, overflow)
ASI07	Inter-Agent Manipulation	Cross-agent injection detection in GoalHijackPlugin
ASI08	Cascading Failure	CircuitBreakerPlugin + per-agent budget caps
ASI09	Trust Exploitation	Attenuation-only delegation (max depth 3)
ASI10	Rogue Agent	CSML auto-escalation + CircuitBreaker auto-trip

19.4 MCP Attack Surface Conformance

Dedicated 10-test suite validates each OWASP ASI category against the gateway choke point using real MCP tool calls.

20. Compliance & Standards Mapping

Standard	Scope	SINT Coverage
OWASP Agentic Top 10	AI agent security	10/10 categories (ASI01–ASI10)
EU AI Act	High-risk AI systems	Art. 9 (risk management → CSML + tier system), Art. 11 (technical documentation → evidence ledger), Art. 13 (transparency → audit trail), Art. 14(4)(e) (stop button → CircuitBreakerPlugin)
IEC 62443	Industrial cybersecurity	Zone/conduit mapping via bridge adapters, SL-T alignment with tier system
ISO 10218-1/2	Industrial robot safety	Force/velocity constraints, collaborative space monitoring, protective stop forwarding
ISO/TS 15066	Collaborative robots	Power-and-force limiting mode, per-body-region contact force limits
ISO 14971	Medical device risk management	Risk classification → tier assignment, residual risk tracking via ledger
IEC 62304	Medical device software	Traceability via evidence ledger, software unit verification
IEC 60601-1-8	Medical electrical equipment alarms	Alarm priority mapping to tier escalation
FDA 21 CFR Part 820	Medical device QMS	Design controls, production records via audit trail
NIST AI RMF 1.0	AI risk management	MAP (resource classification), MEASURE (CSML), MANAGE (tier escalation), GOVERN (audit)
NIST SP 800-82 Rev. 3	OT security	Network segmentation (bridge isolation), access control (tokens), monitoring (ledger)
NATO STANAG 4586	UAS control	Command/control mapping via MAVLink bridge, IFF via capability tokens
ASTM F3548-21	UAS remote ID	Agent identity via Ed25519 keys, broadcast via capability token metadata
FAA AC 107-2B	sUAS operations	Altitude constraints, BVLOS approval mapping to T3
DNV-ST-0111	Subsea systems	ROV action classification, emergency surface priority

21. Competitive Landscape

21.1 Protocol Comparison Matrix

Feature	SINT	MCP (Anthropic)	ACP (IBM/LF)	A2A (Google)	AgentProtocol	ANP	AG-UI
Physical constraints	✅	❌	❌	❌	❌	❌	❌
Graduated authorization	✅ (T0–T3)	❌	Partial	❌	❌	❌	❌
Capability tokens	✅ (Ed25519)	❌	❌	❌	❌	❌	❌
Hash-chain audit	✅ (SHA-256)	❌	❌	❌	❌	❌	❌
Forbidden combo detection	✅ (DFA)	❌	❌	❌	❌	❌	❌
Behavioral drift (CSML)	✅	❌	❌	❌	❌	❌	❌
Circuit breaker	✅	❌	❌	❌	❌	❌	❌
Economic metering	✅	❌	❌	❌	❌	❌	❌
Plugin architecture	✅	❌	✅	❌	❌	❌	❌
Robot/drone bridges	✅ (ROS2, MAVLink)	❌	❌	❌	❌	❌	❌
IoT/OT bridges	✅ (MQTT, OPC-UA)	❌	❌	❌	❌	❌	❌
OWASP ASI coverage	10/10	0/10	~3/10	~1/10	0/10	0/10	0/10
EU AI Act compliance	✅	❌	Partial	❌	❌	❌	❌
Tests	1,363	N/A	N/A	N/A	N/A	N/A	N/A

Key insight: SINT is not competing with these protocols. It is a security enforcement layer that wraps around them. MCP + SINT = secured MCP. A2A + SINT = secured A2A.

21.2 Market Context

Agentic AI market: $10.86B (March 2026), 46% CAGR →$ 52.6B by 2030
Physical AI security: No established market leader; SINT is first-to-market with a comprehensive protocol
ROSClaw (Cardenas et al., 2026): First academic validation of the need for runtime authorization in ROS 2 agentic systems — cites SINT approach
OWASP Agentic Security: Published March 2026; SINT achieved 10/10 coverage within 4 weeks

22. Research Agenda (2026–2031)

Problem 1: Swarm Coordination Security (2026–2027)

Threat: A drone swarm of N agents shares a task. Each individual agent has a valid capability token. But the collective action — N drones converging on a target — is dangerous in ways no individual token expresses. Research directions:

Swarm capability token — Group token encoding collective constraints: maxSwarmDensity (agents/m³), minInterAgentDistance (m), maxCollectiveKineticEnergy (Σ½mv² in joules), synchronizationWindow (ms)
Collective CSML — computeCsml() extended to agent cohorts with tighter threshold θ_swarm
Byzantine-resilient coordination — k-of-N threshold signature scheme for compromised swarm members

Target standard: NATO STANAG 4586 (UAS control), MIL-STD-1553B (bus security)

Problem 2: Sub-Human-Reaction-Time Safety (2026–2028)

Threat: Physical AI operates at 1 kHz (ROS 2 control loops). Human approval has 200–500 ms latency. A robot executes 200–500 control cycles while waiting. Research directions:

Probabilistic constraint envelopes — Replace binary checks with Gaussian confidence bounds
Predictive tier assignment — ML model predicting which upcoming actions will need T2/T3 approval, pre-fetching human attention
Safety-bounded autonomy — Pre-approved trajectory corridors with divergence thresholds for automatic invalidation

Threat: CSML currently tracks action-level metrics. Physical AI decisions are based on sensor fusion (LiDAR + camera + IMU). A compromised sensor can cause correct-looking actions that are physically dangerous. Research directions:

Sensor attestation — Each sensor produces signed readings; gateway verifies sensor integrity
Fusion consistency scoring — Cross-validate sensor modalities; flag inconsistencies
Adversarial sensor detection — Detect spoofed LiDAR, camera injection attacks

Problem 4: Cross-Organizational Trust Federation (2027–2029)

Threat: Agent A (authorized by Company X) needs to interact with Agent B (authorized by Company Y). Neither trusts the other’s token authority. Research directions:

Federated capability negotiation — Mutual attestation protocol
Trust registry integration — Open Agent Trust Registry as the PKI root
Cross-domain CSML — Behavioral reputation that transfers across organizations

Problem 5: Formal Verification of Safety Properties (2028–2031)

Threat: The gateway’s safety invariants are currently tested empirically (1,363 tests). For FDA Class III and aerospace, formal proofs are required. Research directions:

TLA+ specification — Model-check core gateway invariants
Coq/Lean proofs — Formally verify token delegation attenuation
Isabelle/HOL — Prove hash chain integrity properties

23. Deployment & Operations

23.1 Quick Start (MCP Proxy)

For immediate use with Claude Desktop or Cursor:

npm install -g @sint/bridge-mcp
sintctl token create --resource "mcp://*" --actions read,call --ttl 24h

Add to Claude Desktop MCP config:

{
  "mcpServers": {
    "sint-proxy": {
      "command": "npx",
      "args": ["@sint/bridge-mcp", "--downstream", "filesystem,exec"]
    }
  }
}

23.2 Production Deployment (Docker)

# docker-compose.yml
services:
  gateway:
    image: ghcr.io/sint-ai/sint-gateway:latest
    ports:
      - "3000:3000"
    environment:
      - SINT_PERSISTENCE=postgres
      - DATABASE_URL=postgresql://sint:pass@db:5432/sint
      - SINT_REDIS_URL=redis://redis:6379
    depends_on: [db, redis]

  dashboard:
    image: ghcr.io/sint-ai/sint-dashboard:latest
    ports:
      - "3001:80"
    environment:
      - VITE_GATEWAY_URL=http://gateway:3000

  db:
    image: postgres:16
    environment:
      POSTGRES_DB: sint
      POSTGRES_USER: sint
      POSTGRES_PASSWORD: pass
    volumes:
      - pgdata:/var/lib/postgresql/data

  redis:
    image: redis:7-alpine

volumes:
  pgdata:

23.3 CLI (`sintctl`)

# Token management
sintctl token create --resource "ros2:///cmd_vel" --actions publish --maxVelocity 1.5
sintctl token list
sintctl token revoke <tokenId>
sintctl token delegate --parent <tokenId> --maxVelocity 0.5  # Attenuated

# Approvals
sintctl approve list --pending
sintctl approve accept <requestId>
sintctl approve deny <requestId> --reason "Too fast"

# Audit
sintctl ledger query --agent <key> --since 2026-04-01 --tier T3
sintctl ledger verify --entry <entryId>  # Verify hash chain
sintctl ledger export --format jsonl > audit.jsonl

# Policy
sintctl policy list
sintctl policy add --resource "mcp://exec/*" --tier T3_COMMIT
sintctl policy test --resource "ros2:///cmd_vel" --action publish

# Scanning
sintctl scan --server filesystem  # Security scan MCP server

23.4 Python SDK

from sint import SintClient, SintScanner

# Client usage
client = SintClient(gateway_url="http://localhost:3000")
token = client.create_token(
    resource="mcp://filesystem/*",
    actions=["read"],
    ttl_hours=24
)

# Security scanning
scanner = SintScanner(gateway_url="http://localhost:3000")
results = scanner.scan_server("filesystem")
for finding in results.findings:
    print(f"{finding.severity}: {finding.description}")

23.5 Go SDK

import "github.com/sint-ai/sint-protocol/sdks/sint-go"

client := sint.NewClient("http://localhost:3000")
token, err := client.CreateToken(sint.TokenRequest{
    Resource: "ros2:///cmd_vel",
    Actions:  []string{"publish"},
    MaxVelocityMps: 1.5,
})

24. Roadmap

Phase 1: Foundation (Completed — Q1 2026)

✅ Core protocol types and Zod schemas
✅ Policy Gateway with tier assignment and plugin system
✅ Ed25519 capability tokens with delegation chains
✅ SHA-256 hash-chained evidence ledger
✅ MCP bridge adapter (primary adoption vector)
✅ Economic layer with metered billing
✅ OWASP ASI 10/10 conformance
✅ 1,363 tests passing

Phase 2: Bridges & SDKs (Q2 2026)

✅ ROS 2 bridge adapter
✅ MAVLink v2 bridge adapter
✅ Google A2A bridge adapter
✅ gRPC bridge adapter
✅ IoT/MQTT/OPC-UA/Open-RMF bridges
✅ Python SDK (1,962 lines)
✅ Go SDK (stub)
✅ TypeScript client SDK
✅ PostgreSQL persistence (518 lines)
✅ Redis persistence + revocation bus
⭕ npm publish 8 packages to @sint/ scope (ready)
⭕ SPAI 2026 submission (deadline: May 7)

Phase 3: Production Hardening (Q3 2026)

TEE attestation (Intel SGX, ARM TrustZone, AMD SEV)
Formal verification (TLA+ for gateway invariants)
Kubernetes Operator for gateway deployment
Prometheus/Grafana monitoring integration
SIEM export connectors (Splunk, Datadog, ELK)
Edge mode for bandwidth-constrained deployments
SOC 2 Type II audit preparation

Phase 4: Swarm & Federation (Q4 2026 – Q1 2027)

Swarm capability tokens
Collective CSML
Cross-organizational trust federation
Byzantine-resilient coordination
Agent Trust Registry integration as federation root

Phase 5: Formal Safety (2027–2031)

Probabilistic constraint envelopes
Predictive tier assignment
Multi-modal sensor fusion trust
Formal proofs (Coq/Lean/Isabelle)
Medical device certification support (IEC 62304 + FDA)
Aerospace certification support (DO-178C)

25. References

Academic

Cardenas, I.S., Arnett, M.A., Yeo, N.C., Sah, L., Kim, J.-H. (2026). “ROSClaw: An OpenClaw ROS 2 Framework for Agentic Robot Control and Interaction.” arXiv:2603.26997.
OWASP. (2026). “Agentic AI Security Initiative — Top 10 for Agentic AI.” owasp.org.
Anthropic. (2024). “Model Context Protocol Specification.” spec.modelcontextprotocol.io.
MCP Security Analysis. (2026). arXiv:2601.17549.
Google. (2025). “Agent-to-Agent (A2A) Protocol.” github.com/google/A2A.

Standards

IEC 62443-3-3:2013. Industrial communication networks — IT security for networks and systems.
ISO 10218-1:2011. Robots and robotic devices — Safety requirements for industrial robots.
ISO/TS 15066:2016. Robots and robotic devices — Collaborative robots.
ISO 14971:2019. Medical devices — Application of risk management.
IEC 62304:2015. Medical device software — Software life cycle processes.
IEC 60601-1-8:2020. Medical electrical equipment — Alarm systems.
FDA 21 CFR Part 820. Quality System Regulation.
NIST AI RMF 1.0 (2023). Artificial Intelligence Risk Management Framework.
NIST SP 800-82 Rev. 3 (2023). Guide to Operational Technology (OT) Security.
NATO STANAG 4586. Standard Interfaces of UAV Control System.
ASTM F3548-21. Standard Specification for UAS Remote ID.
EU AI Act (2024). Regulation (EU) 2024/1689 — Harmonised rules on artificial intelligence.
DNV-ST-0111. Assessment of station keeping capability of dynamic positioning vessels.

SINT Ecosystem

SINT Protocol Repository. github.com/sint-ai/sint-protocol.
SINT Operators Platform. github.com/sint-ai/sint-agents.
SINT Virtual CMO. github.com/sint-ai/sint-cmo-operator.
SINT Avatars. github.com/sint-ai/sint-avatars.
SINT Outreach. github.com/sint-ai/sint-outreach.
Open Agent Trust Registry. github.com/pshkv/open-agent-trust-registry.
Autonomous Execution Engine. github.com/sint-ai/autonomous-execution-engine.

Appendix A: Gateway Invariants

ID	Invariant	Description
I-G1	Single choke point	All actions pass through Policy Gateway
I-G2	E-stop never blocked	Emergency stop signals are always forwarded
I-G3	Tier monotonicity	Tiers can only escalate during request lifecycle
I-G4	Token attenuation	Delegation can only narrow scope
I-G5	Ledger append-only	Evidence ledger entries never modified or deleted
I-G6	Hash chain integrity	Each entry hash includes previous entry hash
I-G7	Budget fail-deny	Insufficient balance always denies (never escalates)
I-G8	Timeout fail-deny	Approval timeout defaults to deny

Appendix B: Package Dependency Graph

@sint/core
  ├── @sint/gate-capability-tokens
  ├── @sint/gate-policy-gateway
  │     ├── @sint/gate-capability-tokens
  │     ├── @sint/gate-evidence-ledger
  │     └── @sint/bridge-economy
  ├── @sint/gate-evidence-ledger
  ├── @sint/persistence
  │     └── @sint/persistence-postgres
  ├── @sint/bridge-mcp
  │     └── @sint/gate-policy-gateway
  ├── @sint/bridge-economy
  └── @sint/client

Appendix C: Environment Variables

Variable	Default	Description
`SINT_PERSISTENCE`	`memory`	`memory` \| `postgres` \| `redis`
`DATABASE_URL`	—	PostgreSQL connection string
`SINT_REDIS_URL`	—	Redis connection string
`SINT_TOKEN_TTL`	`86400000`	Default token TTL (ms)
`SINT_MAX_DELEGATION_DEPTH`	`3`	Maximum delegation chain depth
`SINT_CSML_THRESHOLD`	`0.30`	Default CSML escalation threshold
`SINT_CIRCUIT_BREAKER_THRESHOLD`	`5`	Consecutive denials to auto-trip
`SINT_APPROVAL_TIMEOUT`	`30000`	Default approval timeout (ms)
`SINT_LOG_LEVEL`	`info`	`debug` \| `info` \| `warn` \| `error`

Getting Started

SINT Protocol

Integrations

Products

Developers

Resources

​A Comprehensive Technical Whitepaper

​Abstract

​Table of Contents

​1. The Problem

​1.1 The Physical AI Gap

​1.2 The Authorization Gap

​1.3 Why Existing Protocols Don’t Solve This

​2. Design Principles

​3. SINT Protocol Architecture

​3.1 System Overview

​3.2 Request Lifecycle (Deterministic Finite Automaton)

​3.3 Monorepo Structure

​4. Core Primitives

​4.1 SintRequest

​4.2 PolicyDecision

​4.3 Resource URI Scheme

​5. Approval Tier System

​5.1 Tier Definitions

​5.2 Tier Escalation Triggers

​5.3 Approval Flow

​6. Capability Token Framework

​6.1 Token Structure

​6.2 Delegation Rules

​6.3 Cryptographic Primitives

​7. Forbidden Combination Detection

​7.1 Default Forbidden Combos

​7.2 Detection Algorithm

​8. Evidence Ledger

​8.1 Ledger Entry

​8.2 Integrity Properties

​8.3 Storage Backends

​8.4 API

​9. Bridge Adapters

​9.1 MCP Bridge (Primary Adoption Vector)

​9.2 ROS 2 Bridge

​9.3 MAVLink Bridge

​9.4 Additional Bridges

​10. Economic Layer

​10.1 Token Unit

​10.2 Billing Formula

​10.3 Tier-Based Cost Table

​10.4 Budget Enforcement

​10.5 Revenue Split (Design)

​10.6 Cost-Aware Route Selection

​11. Safety Plugins

​11.1 GoalHijackPlugin (OWASP ASI01)

​11.2 MemoryIntegrityChecker (OWASP ASI06)

​11.3 DefaultSupplyChainVerifier (OWASP ASI04)

​11.4 CircuitBreakerPlugin (EU AI Act Art. 14(4)(e))

​11.5 DynamicEnvelopePlugin

​11.6 SwarmCoordinator

​12. CSML Behavioral Identity

​12.1 Definition

​12.2 Auto-Escalation

​12.3 ROSClaw Validation

​13. SINT Operators Platform

​13.1 Technical Stack

​13.2 Feature Modules (28 modules)

​13.3 Pages (26 routes)

​13.4 WebSocket Gateway

​14. Virtual CMO Content Engine

​14.1 Pipeline Architecture

​14.2 Technical Stack

​14.3 Skills (18 modular processors)

​14.4 Publishing Integrations

​14.5 Services

​14.6 External Integrations

​14.7 Cost Analysis

​15. 3D Avatar System

​15.1 Architecture

​15.2 Client (apps/client)

​15.3 Server (apps/server)

​15.4 Shared Package (packages/shared)

​15.5 Expression System
